Darcor Standard Duty Hose
| Standard Duty Suction & Discharge Hose |
A very popular hose with clear tube so that material flow can be easily monitored. Recommended for use with
both dry solids and liquids. Hose is lightweight, flexible, and easy to use. Standard Duty Hose has an
abrasion-resistant cover to withstand abuse.
Designed for a broad range of suction and discharge service, Standard Duty Hose is used in construction,
agriculture, industrial, mining and marine applications. PVC tube withstands fertilizer solutions, many industrial
chemical solutions and mild acids. Mirror smooth bore is abrasion-resistant, making this hose well suited for
transfer of dry materials and slurry-like solutions.
Construction:
Clear PVC tube and cover
High-density green helix reinforcement
Temperature Range: +15 to +158 degrees F
both dry solids and liquids. Hose is lightweight, flexible, and easy to use. Standard Duty Hose has an
abrasion-resistant cover to withstand abuse.
Designed for a broad range of suction and discharge service, Standard Duty Hose is used in construction,
agriculture, industrial, mining and marine applications. PVC tube withstands fertilizer solutions, many industrial
chemical solutions and mild acids. Mirror smooth bore is abrasion-resistant, making this hose well suited for
transfer of dry materials and slurry-like solutions.
Construction:
Clear PVC tube and cover
High-density green helix reinforcement
Temperature Range: +15 to +158 degrees F
| Standard Duty Suction & Discharge Hose (Clear/Green Helix - Smooth Cover) |
| Code Number |
| Inside Diameter (Inches) |
| Outside Nominal Diameter (Inches) |
| Working Pressure PSI@ 72 degrees |
| Vacuum Rating In/Merc@ 72 degrees |
| Bending Radius Minimum (Inches) |
| Weight Per Foot (Pounds) |
| Length Standard (Coil) (Feet) |
| DSD-4 |
| 1 |
| 1.26 |
| 106 |
| Full |
| 4.5 |
| .26 |
| 100 |
| DSD-5 |
| 1-1/4 |
| 1.53 |
| 99 |
| Full |
| 5.0 |
| .32 |
| 100 |
| DSD-6 |
| 1-1/2 |
| 1.78 |
| 89 |
| Full |
| 6.0 |
| .38 |
| 100 |
| DSD-8 |
| 2 |
| 2.31 |
| 79 |
| Full |
| 8.0 |
| .58 |
| 100 |
| DSD-10 |
| 2-1/2 |
| 2.85 |
| 65 |
| Full |
| 10.0 |
| .87 |
| 100 |
| DSD-12 |
| 3 |
| 3.38 |
| 65 |
| Full |
| 12.0 |
| 1.04 |
| 100 |
| DSD-16 |
| 4 |
| 4.46 |
| 55 |
| Full |
| 16.0 |
| 1.62 |
| 100 |
| DSD-24 |
| 6 |
| 6.62 |
| 47 |
| Full |
| 36.0 |
| 3.36 |
| 20, 25 |
| DSD-32 |
| 8 |
| 8.85 |
| 40 |
| Full |
| 60.0 |
| 6.10 |
| 20, 25 |
| Phone (937) 558-2497 Fax (937) 698-1247 |
