Spiralite 115
PVC CLEAR STANDARD SUCTION HOSE


HOSEAPPEARANCE/CONSTRUCTION:
Clear PVC with white helix. Smooth wall and
interior


BENEFITS:
-Highly versatile and durable
-Smooth interior prevents material blockage
-Clear wall allows easy inspection


GENERAL APPLICATIONS:
-General suction for water and light chemical
solutions


TEMPERATURE RANGE:
-10°F TO +130°F


STANDARD LENGTHS:
3/4" thru 6" - 100'
8" and above - 20' 25' 30'
Nominal size
inch
3/4"
1"
1-1/4"
1-1/2"
2"
2-1/2"
3"
4"
5"
6"
8"
10"
12"
Appox O.D.
inch
1.02
1.29
1.84
1.84
2.39
2.92
3.46
4.56
5.65
6.80
8.95
11.34
13.39
W.P. at 68°F
PSI
100
100
60
60
40
32
55
50
-
-
-
-
-
W.P at 149°F
PSI
42
42
42
37
32
28
28
-
-
-
-
-
-
Vacuum Rating
in/HG
28
28
28
28
28
28
28
28
28
28
28
28
28
Recom. Min.
Bend Radius at
68°F
inch
2
3
4
4
5
7
8
12
20
23
34
40
50
Approx. B.P. at
68°F
PSI
300
300
270
270
210
195
165
150
135
135
120
120
105
Approx. Wt.
lbs./ft.
.21
.29
.38
.49
.71
.98
1.28
2.02
2.97
4.39
6.79
11.88
15.07
